Viper Clear. Top bend.

The LED strip sleeves Viper are designed for decorative, ambient and indirect lighting applications.
What makes this group of products particularly attractive is their perfect blend of top value, professional quality and a minimalist design. The virtually unlimited length of sleeves and individual segment junctions invisible to the user means that these products are an excellent decorative solutions for large rooms, hallways, etc.
The sleeves are securely sealed from dust, water and offer a wide selection of wiring options. They are also resistant to ambient temperature changes and can be paired with a wide range of top quality Holectron 3-step MacAdam LED modules, 2200K-6500K CRI90+.

Key features

Wide 2200K-6500K white color range

Beam angle: 100°

High CRI 90+

Reverse voltage protection

Lumen output : 100 – 1847 lm

IP65

3-step MacAdam LEDs

Customization for
your project

Power: 1W, 2W, 4W, 7W, 9W, 11W, 14W

L70B50 50.000

Dimmable

Stabilized current design

Thermal resistance: -30° – +50°

24V DC voltage input

Lighting Effect

Applications:

Ambient lighting, decorative lighting, outline architectural lighting

Suitable for indoor and outdoor use.

Beam angle: 100°

Type: White, Tunable white, RGB, RGBW

CRI: 90+

CCT: 2200K – 6500K

sleeves-holectron-29

Ultra compact – 5 mm width

Viper-08 technical drawing

For white light

Viper-09 technical drawing

For Tunable white, RGB, RGBW

Bend radius

Top bend

R = 10 cm (3.94 in)

Bend radius

Top bend

R = 10 cm (3.94 in)

bending-radius2

Mounting

Viper-08 holder

(for FL)

Aluminum profile

Viper-09 holder

(for TW, RGB, RGBW)

Aluminum profile

Modules types

Individual module

Wire from single side

Full module

Wires from both sides

Wire ends

Bare ends

With connector
